Power Locks FA1

POWER LOCKS FA1

POWER LOCKS - FA1

Type FA1 Spc.	Fundamental dimensions				SizesXN	Rated load		Ps Mpa	Ph Mpa	Ma N.m	Weight kg
Type FA1 Spc.	L1	L2	L	Ls	SizesXN	Ft(Kn)	Mt(Kn.m)	Ps Mpa	Ph Mpa	Ma N.m	Weight kg
18X47	17	22	28	34	M6X5	34	0.31	314	125	14	0.26
19X47	17	22	28	34	M6X5	35	0.33	297	125	14	0.27
20X47	17	22	28	34	M6X5	38	0.38	295	125	14	0.27
22X47	17	22	28	34	M6X5	38	0.41	270	125	14	0.28
24X50	17	22	28	34	M6X5	38	0.45	245	120	14	0.29
25X50	17	22	28	34	M6X6	45.6	0.57	285	140	14	0.29
28X55	17	22	28	34	M6X6	45.6	0.63	255	130	14	0.35
30X55	17	22	28	34	M6X6	45.6	0.66	235	130	14	0.36
32X60	17	22	28	34	M6X8	60.6	0.97	295	155	14	0.44
35X60	17	22	28	34	M6X8	60.6	1.06	270	155	14	0.47
38X65	17	22	28	34	M6X8	60.6	1.15	250	145	14	0.48
40X65	17	22	28	34	M6X8	60.6	1.21	235	145	14	0.55
42X75	20	25	33	41	M8X7	98	2.05	295	170	35	0.76
45X75	20	25	33	41	M8X7	98	2.2	290	170	35	0.78
48X80	20	25	33	41	M8X7	98	2.35	270	160	35	0.81
50X80	20	25	33	41	M8X7	98	2.45	260	160	35	0.87
55X85	20	25	33	41	M8X8	112	3.08	270	175	35	0.94
60X90	20	25	33	41	M8X8	112	3.36	245	165	35	1.00
63X95	20	25	33	41	M8X9	126	3.87	260	175	35	1.06
65X95	20	25	33	41	M8X9	126	4.09	250	175	35	1.70
70X110	24	30	40	50	M10X8	179	6.3	280	180	70	1.79
75X115	24	30	40	50	M10X8	179	6.7	260	170	70	1.89
80X120	24	30	40	50	M10X8	179	7.15	250	170	70	1.98
85X125	24	30	40	50	M10X9	200	8.5	260	180	70	2.15
90X130	24	30	40	50	M10X9	200	9.1	250	170	70	2.24
95X135	24	30	40	50	M10X10	224	10.6	260	180	70	3.07
100X145	26	32	44	56	M12X8	268	13.4	270	190	125	3.35
110X155	26	32	44	56	M12X8	268	14.6	240	180	125	3.59
120X165	26	32	44	56	M12X9	298	17.9	250	180	125	5.04
130X180	34	40	54	68	M12X12	400	26	240	170	125	5.33
140X190	34	40	54	68	M14X9	384	27	210	150	190	5.81
150X200	34	40	54	68	M14X10	440	33	230	170	190	6.67
160X210	34	40	54	68	M14X11	470	38	230	170	190	7.61
170X225	44	50	64	78	M14X12	530	45	180	130	190	8.05
180X235	44	50	64	78	M14X12	530	47	170	130	190	8.90
190X250	44	50	64	78	M14X15	590	49	210	150	190	9.58
200X260	44	50	64	78	M14X15	590	52	190	150	190	10.70
220X285	50	56	72	88	M16X12	587	64.5	145	110	355	14.40
240X305	50	56	72	88	M16X15	734	88	165	130	355	15.50
260X325	50	56	72	88	M16X18	880	114	180	145	355	16.70
280X355	60	66	84	102	M18X16	948	132	150	120	485	24.00
300X375	60	66	84	102	M18X18	1059	159	160	125	485	25.50
320X405	74	81	101	121	M20X18	1374	220	150	120	690	38.00
340X425	74	81	101	121	M20X21	1603	272	175	135	690	40.00
360X455	86	94	116	138	M22X18	1710	308	140	110	930	48.00
380X475	86	94	116	138	M22X21	1995	379	155	120	930	57.00
400X495	86	94	116	138	M22X21	1995	399	150	120	930	63.00
